Redarc Manager Alpha75 with RedVision
Redarc Manager Alpha75 with RedVision
Redarc Manager Alpha75 with RedVision

REDARC MANAGER ALPHA75 WITH REDVISION

Regular price $4,899.00
BMS12075-AU
Unit price  per
GST included. Shipping calculated at checkout.
Regular price $4,899.00
BMS12075-AU
Unit price  per

Perfect for charging auxiliary batteries used in recreational vehicles, caravans and camper trailers, the Manager Alpha75 is a complete battery management system. With a combination of DC, AC and solar charging, achieve the best charge for your secondary battery.


Features



CHARGE

the Manager Alpha75 battery management system is capable of delivering 75A of charge from a combination of available power sources including vehicle (DC), mains (AC) and solar. As the next generation of REDARC’s trusted battery management technology, you’ve got power on hand to charge your batteries faster than you can drain them.

No matter whether you’re driving, plugged in at camp or soaking up the sun, run everything from induction cooktops to fridges and air conditioners.

At up to 55% smaller and 28% lighter than competing systems that require multiple parts to deliver the same features, the Manager Alpha range maximises your charge capacity while still leaving room for adventure essentials.

The Manager Alpha75 is able to use excess solar power to keep your start battery charged or bring it back to life in the event of a flat battery with Start Battery Charge and Recovery modes.



MONITOR

Featuring RedVision technology and Bluetooth compatibility, keep on top of your charge and battery level information in real time. The included RedVision display allows you to view state of charge, remaining charge and current flow information and at up to five times more accurate than the leading competitor, you can be sure that “5 hours left” means “5 hours left”.

Incorporating latest Bluetooth 5.1 technology, the Smart Battery Monitor delivers reliability over distances up to 42m so you can stay connected anywhere at camp.



BUILT TOUGH

The Manager Alpha has been tested to the toughest vibration standards in the world and is always ready for adventure. Able to keep charging in the frigid extremes of the highlands or the scorching heat of the outback, it’s made in Australia, so you know it won’t let you down.



MORE FEATURES
  • Simultaneous 75A charging from DC, AC and solar power
  • Up to 55% smaller and 20% lighter than comparable systems
  • Start battery back charge capability
  • RedVision compatibility
  • Bluetooth 5.1 technology
  • 5 times more accurate monitoring than competitors






Specifications




Nominal Voltage 12V
Current Measurement Range ± 500A
Start Battery Input Voltage Range 9-32VDC
Solar Input Voltage Range 9-32VDC
Nominal Output Voltage 12V
Compatible Battery Types Gel, AGM, Calcium, Standard Lead Acid, Lithium
Nominal Current Rating 75A
AC Input Voltage Range 95 – 264 VAC rms / 45 – 65 Hz
Operating Temperature –20°C to 60°C
Weight 6.0kg
height 120mm
width 154mm
depth | length 400mm
Warranty

2 Years
