SWITCH CARLING ILLUM. 12V RED ON/OFF D/POLE R404-12R For Inverter
SWITCH CARLING ILLUM. 12V RED ON/OFF D/POLE R404-12R For Inverter
SWITCH CARLING ILLUM. 12V RED ON/OFF D/POLE R404-12R FOR INVERTER
Regular price $38.50
SW1517
Unit price  per
GST included. Shipping calculated at checkout.
Regular price $38.50
SW1517
Unit price  per
Carling Illuminated Rocker Switch On/Off 12 Volt 20amp.
These snap-in rocker switches offer countless options for ratings, circuits, colors, illuminations and symbols. These single or double pole switches feature removable actuators in a choice of actuator styles and colors, which may be purchased and stocked separately. An optional plug-in terminal connector enables pre-wiring of wire harness.


  • 2 Position - On/Off- Double Pole - Single Throw- Illuminated Black Nylon Actuator.
  • Maximum Load: 20amp at 12 Volt.
  • Actuator illuminates Red independently of switch activation.
  • Silver Contacts. 6 Blade Terminals.
  • Wide Bezel - Snap in mounting.
  • Mounting Panel Hole Width 21.08mm and Height 36.83mm.
  • Water Resistant Switch- IP67 Rating. 1 year Warranty.

Typical Applications

  • On/Off-Highway
  • Marine
  • Armored Vehicles
  • Mining Machinery
  • Any Application Requiring Sealing Protection

Dimensions

Suits panel thickness 2.35mm to 4.73mm.

38.80mm x 49.50mm x 24.30mm.
